Support Customization And Wholesale
Misusing or mishandling lithium ion batteries can pose a SERIOUS RISK of personal injury, property damage, or death
BATTERIES MAY EXPLODE, BURN, OR CAUSE A FIRE IF MISUSED OR MISHANDLED
ONLY use with proper protection circuitry
ONLY use within manufacturer specification
DO NOT store loose in pocket, purse, etc. – always use a protective case
KEEP AWAY from metal objects to prevent short circuiting
DO NOT short circuit
DO NOT use if wrapper or insulator is damaged or torn
DO NOT use if damaged in any way
DO NOT overcharge or over-discharge
DO NOT modify, disassemble, puncture, cut, crush, or incinerate
DO NOT expose to liquids or high temperatures
DO NOT solder
User must be familiar with handling lithium ion batteries before purchase
Usage of batteries is AT YOUR OWN RISK
Rated Capacity:150Ah
Nominal Voltage:12.8V
End of Charge Voltage:14.6V
Charge mode: CC,CV
Charging cut-off current: 0.02C
Charging time: 3-5h
Over-Charge Voltage Protection(cell): 3.65V
Max continuous charge current: 100A
Maximum Continuous Discharging Current: 100A
Over-discharge Voltage Protection(cell): 2.7V
Short circuit protection: With BMS Protection
Short circuit protection Release: Disconnect the load
Operation Temperature Range (Charge):0~45℃
Operation Temperature Range (Discharge): -10~60℃
Storage Temperature Range (3 month):-20℃ ~ 45℃
Storage Temperature Range (1 Year):-20℃ ~ 25℃
Cell Dimension: 415 * 170* 300mm
Weight: 11±0.3Kg
Battery Case: ABS Case
